Introduction

Designing an RF circulator on PCB bridges physics, materials, EM simulation, and practical layout. A good design turns non-reciprocity into system reliability—protecting PAs, improving sensitivity, and simplifying duplexing across bands from L/S to X/Ku/Ka. In this guide, we focus on what matters most for a PCB-integrated circulator: ferrite behavior, biasing, stackup, transitions, and validation.

Fundamentals: What Sets RF Circulators Apart

An RF circulator is a passive, non-reciprocal three-port device that routes power directionally (1→2→3). In PCB realizations, non-reciprocity is achieved using saturated ferrites under a static magnetic bias, causing off-diagonal permeability terms and hence a rotation of RF fields. Key figures of merit include insertion loss (IL), isolation (ISO), return loss (RL/VSWR), bandwidth, and power handling.

• Ferrite selection: YIG and garnet-based ferrites offer low loss at microwave frequencies; saturation magnetization and linewidth set the bias and IL/ISO trade-off.
• Geometry: Junction size sets bandwidth vs. footprint; microstrip/stripline defines confinement and loss.
• Bias point: Over- or under-bias shifts center frequency and degrades isolation. Temperature drift matters.
• Thermal/Power: IL × forward power becomes heat; ensure a thermal path from the ferrite puck to the copper pour or chassis.

S-parameters at the design band should target: IL ≤ 0.5–0.8 dB (PCB variants), ISO ≥ 18–23 dB (application-dependent), and RL ≥ 14–18 dB. Waveguide variants can do better but trade size and cost.

Translating System Needs into Circulator Specs

Start from the link budget and PA/LNA limits. Convert system KPIs into circulator requirements:

• Frequency plan & bandwidth: Decide absolute band and percentage bandwidth; check temperature and manufacturing spread.
• IL budget: Each 0.5 dB of IL after the PA costs ≈ 11–12% EIRP; before the LNA it hurts NF directly.
• Isolation target: Protect PA from VSWR, reduce TX leakage into RX by ≥ ISO. Consider worst-case antenna mismatch.
• Power handling: CW/peak, VSWR at rated power, and derating vs. temperature (copper pour and vias under the ferrite).
• Size & integration: SMT/Microstrip vs. drop-in vs. coaxial; think about reworkability and test.

Topology & PCB Choices

On PCB, microstrip and stripline are most common. Microstrip is easy to prototype and probe; stripline offers better shielding and lower radiation at the cost of via transitions.

• Microstrip junction: Compact, easier magnet access. Needs careful ground via fences and absorbers around discontinuities.
• Stripline junction: Symmetric fields and better isolation; requires plated-through ferrite aperture and tight stackup control.
• Transitions: End-launch/coax to microstrip, microstrip-to-coplanar, or probe launches for wafer/chip-like test.

RF PCB Stackup & Materials

Select laminates with low loss tangent (tanδ ≤ 0.003 at target band) and stable εr. Popular choices include PTFE composites and low-loss hydrocarbon-ceramic laminates. Control:

• Dielectric thickness tolerance (±5–10%)—directly affects Z0 and matching.
• Copper roughness—impacts conductor loss at >10 GHz.
• Bondply/adhesive layers—watch loss and flow around ferrite cavity.
• Thermal path—copper coins, heavy copper under ferrite, thermal vias to heatsink.

For Ka-band, consider thin cores (e.g., 5–8 mil) to keep 50 Ω line widths manufacturable and to tame radiation. Co-planar waveguide with ground (CPWG) helps with isolation and launch repeatability.

Layout Rules that Actually Matter

• Keep reference planes continuous: No neck-downs under junctions; stitch via fences (pitch ≈ λg/20).
• Corner mitering & bends: 45° bends or arc; miter tees to control discontinuities.
• Launch symmetry: Match electrical length from each port to the junction center.
• Absorbers/grounded walls: Use RF absorber “curtains” or cavities to kill spurious modes at the edges.
• Decoupling the bias magnetics: Keep steel/mechanical fasteners away from sensitive fields; prefer non-magnetic hardware.
• Test pads & de-embedding: Place TRL/LRM standards on panel; add probe pads if you plan on-board probing.

Bias Magnet Design & Packaging

Ferrite pucks require a DC magnetic bias to achieve non-reciprocity. You can use permanent magnets (SmCo/NdFeB) above/below the PCB or an integrated yoke. Important considerations:

• Field strength & uniformity: Target saturation with margin; simulate fringing fields around the junction.
• Temperature drift: Magnet Br and ferrite Ms vary with T; consider temp coefficients and derating.
• Shielding: Steel yokes confine flux; prevents interaction with nearby LNAs/filters.
• Assembly: Adhesives and mechanical tolerances affect gap; bias field scales strongly with spacing.

EM Simulation & Co-Design Flow

Adopt a hierarchical flow: circuit-level sizing → 3D EM of junction → co-simulation with launches/packaging → tolerance/temperature sweeps.

1. Start with an equivalent network (RLC + gyrator models) to estimate IL/ISO trends.
2. Build 3D EM of the junction + ferrite + magnets. Use anisotropic ferrite models (μ tensor, linewidth).
3. Extract S-parameters and fit to a rational model; verify group delay and Q-factor.
4. Add coax/microstrip launches and the actual stackup; include screws, vias, and absorber bricks.
5. Run Monte-Carlo on εr, thickness, ferrite Ms, and magnet Br to set production guard-bands.

Prototyping, Calibration & VNA Testing

Define your test plan before layout. Decide on fixtures (end-launch vs. probe), calibration type (SOLT/TRL/LRM), and de-embedding.

• Calibration: Use TRL for PCB coupons; SOLT is fine for coax launches with good standards.
• Power testing: Step power and monitor temperature rise at the ferrite; guard for thermal runaway.
• Stability & intermod: Two-tone tests near rated power to characterize IMD.
• Reliability: Thermal cycling, vibration, and bias magnet aging tests.

Target acceptance metrics (example Ku-band PCB build): IL ≤ 0.7 dB (typ), ISO ≥ 20 dB (typ), RL ≥ 16 dB across 12–18 GHz at 25°C.

DFM/DFA: From Prototype to Production

• Panelize with built-in TRL lines and witness coupons for copper thickness and εr.
• Define magnet fixtures and assembly sequence to control air-gap.
• Specify non-magnetic fasteners where fields are sensitive.
• Document torque specs, adhesive cure profiles, and thermal interface materials.
• Create ICT/functional test with clear pass/fail on IL/ISO/RL.

Common Pitfalls & Debugging Checklist

• Poor coax launches dominate S11—verify standalone and de-embed.
• Under-bias leads to shallow isolation and frequency shift—measure bias field.
• Unaccounted cavity modes near the junction—add absorber or change keep-out.
• Temperature drift moves center frequency—characterize over −40 to +85°C.
• Ferrite loss variability—guard-band with linewidth specs from supplier.

Conclusion

Successful PCB circulator design is a system exercise: pick the right ferrite and bias, engineer the stackup and launches, verify in EM, and prove it on the VNA. Tight control of materials, tolerances, and thermal paths turns the design into repeatable production hardware.

FAQ

Q1: Can I realize a wideband (>30%) PCB circulator?
Yes, but expect trade-offs in IL and size; consider multi-section junctions and careful launch design.

Q2: How to choose ferrite?
Look for saturation magnetization, linewidth, and temperature coefficients appropriate for your band.

Q3: Do I need CPWG?
At Ku/Ka, CPWG improves isolation and launch repeatability versus plain microstrip.

References

• R.E. Collin, Foundations for Microwave Engineering, McGraw-Hill.
• David Pozar, Microwave Engineering, Wiley.
• Manufacturer application notes on ferrite circulators and PCB launches.
