As RF transmitters move to higher power levels and wider bandwidths, the demand for reliable coaxial RF circulators and coaxial RF isolators continues to rise. These non-reciprocal devices are installed directly in the coaxial line to protect power amplifier stages, manage reflections and maintain system linearity in applications such as base stations, radar, SATCOM and high-power test benches.

Building on deep ferrite and microwave engineering experience, HzBeat offers a complete portfolio of coaxial circulators and coaxial isolators that span mainstream communication and radar bands, with options for typical, broadband and high-power designs. This allows RF teams to keep using a familiar coaxial interface, while still meeting new requirements on size, bandwidth and power handling.

A coaxial RF circulator is a three-port non-reciprocal device that routes energy in a single direction (Port 1 → Port 2 → Port 3 → Port 1). A coaxial RF isolator is a two-port version where the third port is internally terminated. In real systems, they are inserted in series with the coaxial cable to:

• Protect power amplifiers from VSWR-related stress and reflected power peaks.
• Improve stability and prevent self-oscillation in sensitive RF chains.
• Enhance effective output power by reducing return loss and mismatch losses.
• Isolate different modules in complex transceiver architectures and phased-array tiles.

Compared with other formats, coaxial RF circulators and isolators are particularly attractive when:

• The system already uses coaxial cabling (rack-mount, outdoor units, test benches).
• High average or peak power must be handled safely over long-term operation.
• The environment is harsh and requires mechanically robust housings and connectors.

HzBeat’s coaxial product line is designed to cover a wide range of communication and radar bands, allowing engineers to standardize on one supplier across multiple platforms and generations.

3.1 Supported Coaxial RF Bands

According to the HzBeat coaxial circulator and coaxial isolator series, the portfolio covers:

• L Band
• S Band
• C Band
• X Band
• Ku Band
• K Band
• Ka Band

This makes it possible to use HzBeat coaxial RF circulators and isolators in common radar, SATCOM, microwave link and base-station front-ends without redesigning the mechanical interface each time.

3.2 Broadband Coaxial RF Circulators and Isolators

For platforms that must cover multiple bands or very wide instantaneous bandwidths, HzBeat offers broadband coaxial RF circulators and corresponding broadband coaxial RF isolators. These products support wide ranges such as 2–6 GHz or 6–18 GHz, helping engineers:

• Use a single coaxial component across several radio models or frequency plans.
• Reduce part count and simplify logistics for global deployment.
• Maintain stable insertion loss and isolation across the entire operating band.

On the circulator side, HzBeat structures its portfolio into clear coaxial families so that engineers can quickly match a device to their system requirements and power levels.

• Typical Coaxial RF Circulators – optimized for mainstream L/S/C/X/Ku/K/Ka band applications, where stable performance, low insertion loss and competitive cost are the priority. These models are widely used in standard RF front-ends and laboratory setups.
• High-Power Coaxial RF Circulators – designed for demanding transmit chains and pulse radar stages that must safely handle high CW and pulsed power while maintaining reliable isolation and low temperature rise.
• Broadband Coaxial RF Circulators – covering wide frequency ranges, ideal for multi-band radios, EW systems and test instrumentation where flexibility and bandwidth are more important than ultra-narrow optimization.

Within each family, HzBeat can further fine-tune the coaxial RF circulator to align with customer needs:

• Connector type: SMA, N-type, 2.92 mm, TNC and other interfaces.
• Preferred operating band and relative bandwidth.
• Target insertion loss, isolation and VSWR windows.
• Mechanical envelope and mounting hole patterns.

When only two ports are needed and a termination is integrated, the coaxial circulator becomes a coaxial RF isolator. HzBeat offers matching coaxial isolator series so that RF designers can choose either three-port or two-port solutions with consistent performance.

• Typical Coaxial RF Isolators – used directly at the output of a power amplifier or sensitive module to provide one-way transmission and robust protection against reflected power.
• High-Power Coaxial RF Isolators – for systems where high peak or average power is the main risk factor, such as radar transmitters, high-power industrial RF heating and EMC setups.
• Broadband Coaxial RF Isolators – providing strong isolation and controlled VSWR across wide operating ranges, especially useful in wideband test systems or multi-service platforms.

In many projects, the coaxial RF isolator must fit into an already crowded enclosure. HzBeat therefore supports custom coaxial RF isolator designs, adapting the connector location, housing shape and mounting options to the mechanical environment while preserving the electrical performance.

Coaxial RF circulators and isolators from HzBeat are widely applied across multiple markets and system types:

• 5G / 6G base stations and small cells – protection for PA modules, RF units and outdoor radio heads, where coaxial RF circulators and coaxial RF isolators handle mismatch from changing antenna conditions.
• Phased-array radar and surveillance systems – isolation between T/R modules, power stages and distribution networks to prevent interaction between channels.
• SATCOM ground terminals – ensuring robustness against antenna mismatch, ice loading and environmental changes across L, S, C, X, Ku, K and Ka bands.
• Microwave links and point-to-point radios – improving transmit efficiency, link budgets and long-term reliability in carrier and private networks.
• High-power test and measurement benches – safe handling of reflections from loads, fixtures and devices under test in laboratories and production lines.

In all these scenarios, the combination of high power capability, broadband operation and rugged mechanical construction makes coaxial solutions from HzBeat a practical choice for engineering teams that must deliver reliable systems on tight schedules.

When selecting the right component, engineers usually start from the system topology, then narrow down to specific coaxial RF circulator or coaxial RF isolator part numbers.

7.1 Circulator vs. Isolator

• Choose a coaxial RF circulator when three ports are beneficial – for example, when routing reflected power into a dummy load or combining transmit/receive paths in duplex architectures.
• Choose a coaxial RF isolator when only two ports are needed and the main goal is to provide one-way transmission and robust protection for a single block such as a power amplifier.

7.2 Key Selection Parameters

For both coaxial RF circulators and coaxial RF isolators, the following parameters are critical:

• Frequency band and bandwidth – must match or exceed the system operating range.
• Power rating – both CW and peak power levels, plus duty cycle if pulsed.
• Insertion loss – lower loss preserves EIRP and reduces unnecessary heat.
• Isolation – higher isolation provides better protection and decoupling.
• VSWR – good matching at all ports minimizes reflections and ripple.
• Connector type – SMA, N-type, 2.92 mm, TNC etc., compatible with existing cables.
• Environmental rating – temperature range, vibration, humidity and sealing level.

If a standard catalog coaxial RF circulator or coaxial RF isolator does not fully meet the requirement, HzBeat can adjust the design window through its customized RF component service, balancing performance targets with realistic manufacturing and cost.

A coaxial RF circulator integrates directly into the coaxial cable run, supports high power levels and offers excellent isolation and low insertion loss over its specified band. It is a natural choice for rack-based systems, outdoor units and test benches where coaxial lines are already used and mechanical robustness is essential.

Q1. What is the main advantage of a coaxial RF circulator compared with other package types?

A coaxial RF circulator integrates directly into the coaxial cable run, supports high power levels and offers excellent isolation and low insertion loss over its specified band. It is a natural choice for rack-based systems, outdoor units and test benches where coaxial lines are already used and mechanical robustness is essential.

Q2. When should I use a broadband coaxial RF circulator or isolator?

If your design must operate across multiple adjacent bands (for example 2–6 GHz or 6–18 GHz) or you want a single part number for several platforms, a broadband coaxial RF circulator or broadband coaxial RF isolator can simplify logistics and reduce redesign efforts. The trade-off is that extremely wide bandwidths may require more careful system-level matching.

Q3. Can HzBeat support customized connectors and mechanical outlines?

Yes. HzBeat can tailor coaxial RF circulators and coaxial RF isolators with different connectors, footprints, mounting flanges and interface details to fit your enclosure and cable layout, while keeping the required RF performance and reliability.

Q4. What information should I prepare before requesting a quote?

It is helpful to provide target frequency band, required bandwidth, power level (CW and peak), minimum isolation, maximum insertion loss, VSWR targets, connector type and any special environmental conditions such as temperature, altitude or vibration. With this data, the HzBeat team can quickly recommend a suitable standard coaxial RF circulator / isolator or a custom solution.
